In the design of industrial peripherals and professional-grade data equipment, the USB Type-B interface is the preferred choice for robust, high-retention connectivity. The USB 2.0 Type-B Female (BF) 180-Degree 15mm Connector by Pran Electronics Pvt. Ltd. is a top-entry, vertical mounting solution engineered for maximum durability and board space efficiency.

With a standardized 15mm body height, this vertical connector is designed for devices where a traditional side-entry port is not feasible, allowing for top-panel access in compact or specialized enclosures.

Engineered for Vertical Stability and Performance

The 180-degree (Vertical) USB Type-B connector offers unique mechanical and design advantages, particularly for stationary equipment:

• High-Retention Type-B Interface: The square Type-B profile is physically larger and more robust than Type-A, providing superior mechanical grip. This makes it ideal for heavy-duty cables used in industrial printers, medical devices, and laboratory instruments.

• Minimal Board Footprint: The vertical orientation consumes significantly less horizontal PCB real estate compared to a 90-degree version, allowing engineers to place more components in high-density layouts.

• 15mm Vertical Profile: The 15mm height ensures the connector is tall enough to clear surrounding surface-mount components while aligning perfectly with top-mounted enclosure cutouts.

• Reinforced PCB Anchorage: Features sturdy through-hole (THT) metal shielding pins that provide a deep, secure anchor to the board. This structural reinforcement prevents mechanical failure during the high-force insertion characteristic of Type-B cables.

Key Features & Technical Specs

• USB 2.0 High-Speed Compliance: Supports stable data transfer rates up to 480 Mbps, ensuring seamless communication between peripherals and host systems.

• Premium Gold-Plated Contacts: Selective gold plating over nickel on the contact pins ensures low electrical resistance and excellent protection against corrosion, even in high-humidity environments.

• Full Metal Shielding: Encased in a nickel-plated brass or steel shell for 360 degree Electromagnetic Interference (EMI) protection, crucial for maintaining signal integrity in electronically noisy industrial settings.

• Industrial-Grade Housing: Molded from UL 94V-0 rated high-temperature thermoplastic, making it resilient against wave soldering heat and long-term operation in demanding temperatures.

• Make in India Excellence: Produced by Pran Electronics Pvt. Ltd., an ISO-certified manufacturer delivering international quality standards with localized logistics benefits.

Technical Specifications
